Ahuja FMX-108DP Mixer

General

• 8-channel PA mixer.

• Operates on 220-240 V AC, 50 Hz mains.

• Weight: approx. 1.85 kg (some listings show ~2.0-2.8 kg).

• Dimensions: W 345 × H 75 × D 210 mm approx.

Inputs & Channels

• 2 balanced XLR mic inputs with switchable +48 V phantom power. Additionally, up to 4 low-impedance mics via 6.3 mm (¼″) jack (balanced or unbalanced).

• Up to 6 line-level signal sources can be connected via 6.3 mm (¼″) jack (balanced/unbalanced) for line inputs.

• One independent stereo input channel (with gain, 2-band EQ, FX & level controls).

Control Features

• Each channel features GAIN control for mic/line input sensitivity. Two-band EQ (Bass & Treble) per channel (e.g., ±15 dB at ~80Hz / ~12kHz) in line input specs.

• Separate FX (effects) level control on each channel.

• Built-in digital effects processor (delay, repeat, level controls) with FX ON/OFF switch and related LEDs.

Other Features

• Built-in MP3 player with USB recording/playback.

• Bluetooth facility for wireless audio input.

• Line-level outputs (Left & Right) via 6.3 mm (¼″) jack sockets.

• Headphone output via 6.3 mm (¼″) jack with independent volume control.

• LEDs on each channel: PEAK LED to indicate excessive input level; also master output SIGNAL & CLIP LEDs.

Performance Specs

From one detailed spec listing:

• Mic input impedance/gain: 2 kΩ balanced / 1 kΩ unbalanced, gain ~ +65 dB.

• Line input impedance/gain: 20 kΩ balanced / 10 kΩ unbalanced, gain ~ +45 dB.

• Frequency response: ~25 Hz to 20 kHz (-1 dB) for line input.

• THD (Total Harmonic Distortion): < 0.1 %.

• Nominal line output level: 0 dBu (775 mV); Maximum: +21 dBu (9 V).

• Output impedance: 600 Ω.

• S/N (Signal-to-Noise ratio): > 68 dB.

• Headphone output: 200 mV at 8 Ω.
