ZKTeco ZKP8005 Technical Specifications

Specification Category	Parameter Details
Print Method	Direct Thermal Line Printing
Print Speed	220mm/s to 300mm/s (varies by firmware configuration)
Print Width	72mm
Print Resolution	576 dots/line or 512 dots/line
Paper Width	79.5 ± 0.5mm
Paper Thickness	0.060 ~ 0.08mm
Roll Diameter	Max 83mm
Print Command	Compatible with ESC / POS
Line Spacing	3.75mm (Adjustable by command)
Fonts & Character Size	Font A: 12×24 dots, 1.5(W) × 3.0(H) mm Font B: 9×17 dots, 1.1(W) × 2.1(H) mm Chinese: 24×24 dots, 3.0(W) × 3.0(H) mm
1D Barcode Types	UPC-A / UPC-E / JAN13(EAN13) / JAN8(EAN8) / CODABAR / ITF / CODE39 / CODE93 / CODE128
2D Barcode Types	QR Code
Hardware Life	Printer Head (TPH): 100 KM Auto Cutter: 1.5 million cuts
Interface Options	USB + LAN (Standard Ethernet) or Optional Parallel/Serial
Storage Capacity	CPU Storage: 64 Kbytes Flash Storage: 256 Kbytes
Power Supply Adapter	Input: AC 100-240V, 50-60 Hz Output: DC 24V / 2.5A
Cash Drawer Output	DC 24V / 1A
Physical Dimensions	186 x 145 x 140 mm (or 192 x 145 x 133 mm depending on base casing)
Net Weight	1.00 Kg to 1.50 Kg (Unit only)
Operating Environment	Temperature: 0℃ to 45℃ Humidity: 10% to 80% RH
Storage Environment	Temperature: -10℃ to 60℃ Humidity: 10% to 90% RH
Software Driver Support	Windows (XP, Vista, 7, 8, 10, 11), Linux
Certifications	CE, FCC, RoHS
