Feature / Category

Specification Details

Interface

16 × 10/100Mbps RJ45 ports (Auto-Negotiation, Auto MDI/MDIX)

Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3x (Flow Control), IEEE 802.3az (Energy Efficient)

Data Transmission Rate

10/100Mbps (Half-duplex), 20/200Mbps (Full-duplex)

Switching Capacity

3.2 Gbps

MAC Address Table

8K entries, supports auto-learning & auto-aging

Jumbo Frame

2KB

Transmission Method

Store and Forward

Power Supply

DC 9V/500mA (Output)

LED Indicators

Power (PWR), 1 × 16 × Port Activity

Dimensions

230 × 230 × 70 mm

Design / Cooling

Fanless (silent operation)

Operating Temperature

0°C ~ 40°C

Storage Temperature

-40°C ~ 70°C

Operating Humidity

10% ~ 90% non-condensing
