रु 3,800

Only 5 in stock

Parameter	Specification
Data Rate	10/100/1000 Mbps (Auto-adaptive)
Standards	IEEE 802.3, 802.3u (100Base-TX/FX), 802.3ab (1000Base-T), 802.3z (1000Base-SX/LX)
Copper Port	1 x RJ45 (Auto-MDI/MDI-X)
Fiber Port	1 x SC (Single Mode or Multi-mode variants available)
Wavelength	1310nm / 1550nm (Single Mode) or 850nm (Multi-mode)
Transmission Distance	Single Mode: Up to 20km (Standard); Multi-mode: Up to 550m
Forwarding Mode	Store and Forward
LED Indicators	Power (PWR), Link/Act, FDX (Full Duplex), 1000M
Power Supply	External DC 5V / 1A or 2A
Power Consumption	≤ 5W
Dimensions	~ 94mm x 70mm x 25mm
Operating Temp	0°C to 70°C

Parameter

Specification

Data Rate

10/100/1000 Mbps (Auto-adaptive)

Standards

IEEE 802.3, 802.3u (100Base-TX/FX), 802.3ab (1000Base-T), 802.3z (1000Base-SX/LX)

Copper Port

1 x RJ45 (Auto-MDI/MDI-X)

Fiber Port

1 x SC (Single Mode or Multi-mode variants available)

Wavelength

1310nm / 1550nm (Single Mode) or 850nm (Multi-mode)

Transmission Distance

Single Mode: Up to 20km (Standard); Multi-mode: Up to 550m

Forwarding Mode

Store and Forward

LED Indicators

Power (PWR), Link/Act, FDX (Full Duplex), 1000M

Power Supply

External DC 5V / 1A or 2A

Power Consumption

≤ 5W

Dimensions

~ 94mm x 70mm x 25mm

Operating Temp

0°C to 70°C
